Double Rotary Sheet Cutting Machine

High-speed double rotary paper sheeter for 200–1000 GSM paper and board converting

The S1500 Double Rotary Paper Sheeter Machine is designed for high-speed roll-to-sheet converting of medium and heavy paper and board materials.

Featuring a double-rotary cutting system, support for 2-roll cutting, and a maximum cutting speed of 300m/min, the S1500 is suitable for paper converters and packaging manufacturers that require stable, continuous sheet production.

The machine handles paper weights from 200–1000 GSM, with a maximum finished width of 1500mm and finished sheet lengths from 450–1700mm.

For manufacturers processing packaging paper, cardboard and other heavier paper grades, the S1500 provides a productive solution for continuous roll-to-sheet cutting.

Send us your paper GSM, reel dimensions, required sheet size and production capacity for machine selection and quotation.

Double Rotary Sheet Cutting Machine Specification

Main Features

Double-Rotary Cutting System

The S1500 uses a double-rotary cutting system designed for continuous roll-to-sheet production.

Compared with conventional intermittent cutting processes, rotary cutting is well suited to high-speed production where stable sheet length and continuous material feeding are required.

This makes the machine suitable for industrial paper converting lines processing medium and heavy paper grades.

High-Speed Paper Sheeting

The machine delivers:

• Maximum cutting speed: 300m/min

• Maximum speed of cutting: 450cuts/min

This production capability makes the S1500 suitable for high-volume paper sheeting operations where throughput is an important purchasing consideration.

Actual output depends on the material, paper weight and correct operating process.

Supports 2-Roll Cutting

The machine supports:

Num.of rolls cutting: 2rolls

This configuration is suitable for production environments that require efficient roll-to-sheet converting and continuous material processing.

Handles Paper from 200–1000 GSM

The S1500 is designed for paper weights ranging from:

200–1000 GSM

This makes it particularly suitable for medium and heavy paper and board materials used in packaging, printing and industrial converting.

Designed for High-Volume Roll-to-Sheet Production

For industrial paper converters, sheeting performance depends on more than cutting accuracy alone.

Production speed, paper weight range, reel handling capability, finished sheet dimensions and continuous operating stability all affect overall productivity.

The S1500 double rotary paper sheeter machine combines high-speed cutting with a wide GSM range and large reel capacity to support continuous production.

It can process reels with a maximum diameter of:

1800mm (71")

and produce finished sheets with:

• Maximum finished width: 1500mm

• Finished sheet length: Min.450-Max.1700 mm

Core Advantages of the S1500 Double Rotary Paper Sheeter

1. Double Rotary Cutting for Continuous Production

The double-rotary cutting structure is designed for continuous high-speed paper sheeting.

It is particularly suitable for production environments where large-volume roll material needs to be converted into consistent finished sheets.

2. Up to 450 Cuts per Minute

The specified maximum cutting frequency is:

450cuts/min

Combined with a maximum cutting speed of 300m/min, the machine provides strong productivity for large-volume converting requirements.

3. Suitable for Heavy Paper and Board

With a paper weight range of 200–1000 GSM, the machine can process heavier materials than many general-purpose paper sheeters.

This makes it suitable for paperboard and packaging material converting where both speed and stable cutting performance are required.

4. Two-Roll Cutting Capability

The S1500 supports 2rolls cutting, providing greater production flexibility for industrial paper converting operations.

5. Flexible Finished Sheet Sizes

The machine supports:

Finished width: Max 1500mm

and:

Finished sheet-Length: Min.450-Max.1700 mm

This allows manufacturers to produce different sheet specifications according to downstream printing, packaging or converting requirements.

Applications

Packaging Paper and Board

The S1500 double rotary paper sheeter is suitable for roll-to-sheet converting of paper and board used for packaging production.

Typical downstream applications include:

• Folding carton materials

• Industrial packaging sheets

• Gift box materials

• Consumer product packaging

• Printed packaging board

• General packaging paper

Paper Converting Plants

For paper converters supplying finished sheets to printers, packaging factories and other downstream users, the S1500 provides a high-speed solution for converting jumbo reels into specified sheet sizes.

Printing Material Preparation

The machine can be used to prepare sheet materials before downstream printing, laminating, die cutting and packaging operations.

Heavy Paper and Board Processing

Its 200–1000 GSM working range makes it suitable for manufacturers handling heavier paper grades and board materials that require continuous roll-to-sheet cutting.

Double Rotary vs. Conventional Paper Sheeting

The main advantage of a double rotary paper sheeter machine is its ability to combine continuous material feeding with high-speed cross cutting.

For factories processing large production volumes, machine selection should consider:

• Required paper GSM

• Reel size

• Finished sheet dimensions

• Required cutting speed

• Required cutting accuracy

• Number of rolls

• Downstream production requirements

The S1500 is particularly suitable when the application requires high-speed sheeting of 200–1000 GSM paper and board.

Cutting Accuracy for Different Sheet Lengths

The S1500 provides specified cutting accuracy according to the finished sheet length:

• ±0.2mm(L<1000mm)

• ±0.1% (L≥1000mm)

This allows manufacturers to evaluate the machine according to their required sheet dimensions and downstream processing tolerances.

Who Should Choose the S1500 Paper Sheeter?

The S1500 is particularly suitable for manufacturers looking for:

• A double rotary paper sheeter machine

• High-speed roll-to-sheet production

• Paper processing from 200–1000 GSM

• Maximum 1500mm finished width

• Cutting speeds up to 300m/min

• Cutting frequency up to 450cuts/min

• Two-roll cutting capability

• Industrial-scale paper and board converting

For applications where production speed and heavier paper grades are key requirements, the S1500 offers a different machine configuration from general-purpose paper sheeters.

Why Choose Our Double Rotary Paper Sheeter?

High-Speed Industrial Configuration

The S1500 is designed for continuous industrial paper converting, with maximum cutting speeds of 300m/min.

Wide Paper Weight Range

Processes paper and board from 200–1000 GSM, making it suitable for different packaging and converting applications.

2-Roll Cutting

The machine supports 2rolls cutting for industrial production requirements.

Flexible Sheet Dimensions

Finished sheet lengths from 450–1700mm and widths up to 1500mm provide flexibility for different downstream applications.

Application-Based Machine Selection

We can evaluate the machine according to your paper type, GSM, reel size, finished sheet dimensions and required output.

How to Select the Right Double Rotary Paper Sheeter

Before requesting a quotation, we recommend providing:

• Paper type

• Paper weight in GSM

• Reel diameter

• Reel width

• Required finished sheet width

• Required sheet length

• Required production capacity

• Local voltage

• Downstream application

These details help determine whether the S1500 configuration matches your production requirements.

If you are comparing different paper sheeting machines, machine selection should be based on material range, working width, cutting system, speed and finished sheet requirements rather than machine speed alone.

Get a Paper Sheeting Solution for Your Production

The S1500 Double Rotary Paper Sheeter Machine is designed for manufacturers that need high-speed roll-to-sheet converting of medium and heavy paper and board.

With double-rotary cutting, 2-roll capability, 200–1000 GSM processing range, maximum 1500mm finished width and up to 300m/min cutting speed, it is suitable for demanding industrial paper converting applications.

Send us your paper specifications and required finished sheet size to receive a suitable machine recommendation and quotation.

Frequently Asked Questions

What is a double rotary paper sheeter machine?

A double rotary paper sheeter machine converts paper reels into finished sheets using a rotary cutting system. It is commonly used in high-speed paper and board converting applications where continuous roll feeding and high production efficiency are required.

What paper weight can the S1500 process?

The specified paper weight range is 200-1000 GSM.

What is the maximum finished sheet width?

The specified finished width is Max 1500mm.

What finished sheet lengths can the machine produce?

The specified finished sheet-length range is Min.450-Max.1700 mm.

How many rolls can the S1500 cut?

The specified number of rolls cutting is 2rolls.

What is the maximum cutting speed?

The specified maximum cutting speed is 300m/min.

How many cuts can the machine make per minute?

The specified maximum speed of cutting is 450cuts/min.

What is the cutting accuracy?

The specified cutting accuracy is ±0.2mm(L<1000mm) and ±0.1% (L≥1000mm).

What is the maximum reel diameter?

The specified maximum reel diameter is 1800mm(71").

Is the S1500 suitable for heavy paper and board?

The machine has a specified paper weight range of 200–1000 GSM, making it suitable for medium and heavy paper and board within the machine's operating requirements.

How do I know whether the S1500 is suitable for my production line?

Send us your paper material, GSM, reel dimensions, required sheet width and length, and expected production capacity. We can evaluate whether the S1500 is suitable for your application.
